Aluminium Channels

Page Menu
Overview

Aluminium Channel Extrusions

InfraBuild Steel Centre supplies an extensive range of aluminium channel extrusions in a variety of grades, including both architectural alloy and structural alloy.

Aluminium channel extrusions can be supplied according to AS/NZS 1866:1997.

Typical Uses

  • Balustrades
  • Building and construction
  • Cool rooms
  • Fences
  • Louvres and sun protection
  • Marine
  • Mining and industrial equipment
  • Signage transport

Features

  • A wide range of aluminium channel sizes
  • A variety of grades of aluminium channel extrusions

Relevant Standards

  • AS/NZS 1866: Aluminium And Aluminium Alloys – Extruded Rod, Bar, Solid And Hollow Shapes

To find out more about the range of aluminium channel extrusions stocked at your local InfraBuild Steel Centre please contact your nearest branch.

Specifications
A B C T1 T2 Die Alloy/Temper Length (mm) Mass/LEN
10 10 10 1.6 EK9146 6060 T5 6500 0.754
12 12 12 1.6 EK9149 6060 T5 6500 0.917
12 20 20 2.5 EK9151 6060 T5 6500 2.061
16 16 16 1.6 EK9152 6060 T5 6500 1.261
20 20 20 1.6 EL1812 6060 T5 6500 1.593
20 20 20 3 EK9155 6060 T5 6500 2.841
22.32 20 20 1.2 RAD EN4619 6060 T5 6500 1.286
25 12 12 3 EK9156 6060 T5 6500 2.262
25 25 25 1.6 EL5249 6060 T5 6500 2.015
25 25 25 3 EK9158 6060 T5 6500 3.627
25 40 40 3 EK9159 6060 T5 6500 5.213
32 16 16 1.6 E20784 6060 T5 6500 1.703
32 25 25 3 EK9160 6060 T5 6500 4.004
40 20 20 2 EQ1556 6060 T5 6500 2.665
40 20 20 3 EK9161 6060 T5 6500 3.894
40 25 25 3 EK9162 6060 T5 6500 4.42
40 40 40 3 E20790 6060 T5 6500 6
44.45 25.4 25.4 3.18 EG1021 6060 T5 6500 4.96
50 25 25 3 EK9215 6060 T5 6500 4.947
50 50 50 3 EK9163 6060 T5 6500 7.579
53 25 25 1.5 E20830 6060 T5 6500 2.43
54.2 20 20 1.6 E20821 6060 T5 6500 2.555
60 32 32 3 EK9164 6060 T5 6500 6.214
A B C T1 T2 Die Alloy/Temper Length (mm) Mass/LEN
76.2 38.1 38.1 RAD EG6435 6060 T5 6500 16.398
80 25 25 3 EK9165 6060 T5 6500 6.526
80 40 40 4 EK9166 6060 T5 6500 10.673
80 40 40 4 RAD E20921 6060 T5 6500 9.882
80 40 40 6 RAD E20922 6060 T5 6500 14.496
100 25 25 3 EK9168 6060 T5 6500 7.579
100 50 50 3 EB1208 6060 T5 6500 10.212
100 50 50 5 RAD EN3527 6060 T5 6500 19.455
100 50 50 6 RAD 9 EN3528 6060 T5 6500 26.593
100 50 50 7.56 RAD EP13664 6060 T5 6500 N/A
101.6 50.8 50.8 7.9 RAD 6.3 EG6434 6060 T5 6500 22.452
Processing

InfraBuild Steel Centre can provide the following processing services for this product:

  • Cut-to-length

To find out more about the processing services offered by InfraBuild Steel Centre please contact your nearest branch.

Delivery

InfraBuild Steel Centre can provide delivery services for this product.

Please contact your nearest branch for more information.
