Ribbed Rectangular Mesh

Ribbed Rectangular Mesh supplied by InfraBuild Reinforcing is a Class L mesh made from 500 MPa wire. Ribbed Rectangular Mesh is commonly used in reinforced concrete slabs such as pavements, precast panels, warehouse and industrial shed slabs, tilt-up slabs, driveways and patio slabs.

Note: Always consult with an engineer before choosing the mesh best suited for your application as using the wrong mesh size could potentially result in failure to your concrete structure.

Typical Uses

Concrete pavements
Flooring
Precast concrete sections
Suspended Flooring

FeaturesMutli-purpose rectangular mesh

Mutli-purpose rectangular mesh
Manufactured from L grade ribbed wires, welded together with different spacing in each direction to form rectangular apertures

Relevant Standards

AS/NZS 4671 Steel for the reinforcement of concrete
AS 3600 Concrete structures
AS 3727 Guide to residential pavements
AS 2870 Residential slabs and footings

To find out more about the Ribbed Rectangular Mesh stocked at your local InfraBuild Reinforcing please contact your nearest bar shop.

Specifications

Product Code	Std Unit	Longitudinal Wires**	Cross Wires**	Mass (kg)	Effective Area (m)
RL718	Sheet	25 x 6.75 @ 100	30 x 7.6 @ 200	67	5.8 x 2.4
RL818	Sheet	25 x 7.6 @ 100	30 x 7.6 @ 200	79	5.8 x 2.4
RL918	Sheet	25 x 8.6 @ 100	30 x 7.6 @ 200	93	5.8 x 2.4
RL1018	Sheet	25 x 9.5 @ 100	30 x 7.6 @ 200	109	5.8 x 2.4
RL1118	Sheet	25 x 10.7 @ 100	30 x 7.6 @ 200	130	5.8 x 2.4
RL1218	Sheet	25 x 11.9 @ 100	30 x 7.6 @ 200	157	5.8 x 2.4

*Number of Wires x Diameter (mm) @ Spacing (mm)
