Wall Bars and Starter Bars – Reinforcing Bar
Overview
Wall Bars and Starter Bars – Reinforcing Bar
Wall bars and starter bars supplied by InfraBuild Reinforcing are used to tie concrete or masonry walls to slabs and footings. InfraBuild Reinforcing’ wall bars and starter bars are available in 12mm and 16mm bar diameters and in variable dimensions. Table below features some of our stock sizes.
Typical Uses
- Tying concrete or masonry walls to slabs and footings
Features
- Available in 12mm and 16mm bar diameters
- Various lengths available
Relevant Standards
- AS/NZS 4671 Steel for the reinforcement of concrete
To find out more about the range of wall bars and starter bars stocked at your local InfraBuild Reinforcing please contact your nearest bar shop.
Specifications
Product Code | Bar diameter (mm) | Dimensions (mm) | Mass (kg) |
N12L5050 | 12 | 500 x 500 | 0.9 |
N12L8020 | 12 | 800 x 200 | 0.9 |
N12L10015 | 12 | 1000 x 150 | 1.05 |
N12L10020 | 12 | 1000 x 200 | 1.05 |
N12L6060 | 12 | 600 x 600 | 1.1 |
N12L10515 | 12 | 1050 x 150 | 1.1 |
N12L26015 | 12 | 2600 x 150 | 2.5 |
N16L7070 | 16 | 700 x 700 | 2.27 |
N16L8080 | 16 | 800 x 800 | 2.59 |
N16L10018 | 16 | 1000 x 180 | 1.91 |
N16L6060 | 16 | 600 x 600 | 1.94 |
N16L26015 | 16 | 2600 x 150 | 4.45 |
Starter Bars (Darwin Only)
Product Code | Bar diameter (mm) | Dimensions (mm) | Mass (kg) |
N12HL100150 | 12 | 1000 x 150 | 1.24 |
N12V10045 | 12 | 65 x 450 x 100 | 0.56 |
