Reidbar™ Processed Galvanized/Black

Reidbar™ Processed Black/Galvanized

Reidbar™ supplied by InfraBuild Reinforcing is suitable for civil construction solutions and is ideal for beams, columns, slab-to-slab, core wall and beam-to-slab applications.

The Reidbar™ System features continuously threaded, hot rolled, Grade 500N reinforcing bar (rebar) that can be cut at any point along its length, then simply joined end to end by a coupler. This unique feature enables an entirely new approach to reinforcement placing and fixing. It is suitable for very thin concrete sections, such as wall panels, and offers a full range of threaded fittings for joining, anchoring and terminating.

The Reidbar™ System reduces bar congestion problems and eliminates cast-in starter bars to simplify transport and handling. It also eliminates the need to drill holes in formwork and shutters for starter bars. No special tools are necessary to tighten Reidbar™ components.

NOTE: InfraBuild Reinforcing does not recommend Reidbar™ for formwork use.

Typical Uses

• Beams, columns, slab-to-slab, core wall and beam-to-slab applications

Features

• A continuously threaded, hot-rolled Grade 500N reinforcing bar that can be cut at any point along its length, then simply joined end to end by a coupler
• Ultimate strength development is possible with short embedment depths
• Suitable for very thin concrete sections, such as wall panels
• Full range of threaded fittings for joining, anchoring and terminating
• Splice at any point along the bar without specialised splicing equipment
• Reduces bar congestion problems – laps, cogs, eliminated in heavily reinforced areas
• Eliminates cast-in starter bars to simplify transport and handling
• Eliminates the need to drill holes in formwork and shutters for starter bars

Relevant Standards

• AS/NZS 4671:2001 Steel reinforcing materials

To find out more about the range of Reidbar™ products stocked at your local InfraBuild Reinforcing please contact your nearest bar shop.
